Intelligent solutions save time, money, and costly man hours of sought-after experts. This is true especially for complex projects such as in HMI creation. CGI Studio 3.12 features several intelligent solutions to everyday challenges in HMI creation, for example: The Fusion Editor, an enhanced Smart Importer with Figma import, an upgraded help system, a large set of 3D primitives, and support for vector graphics.

CGI Studio 3.12 highlights include: The new enhanced Smart Importer now supports the import of Figma files – while recognizing controls more precisely. With the new Fusion Editor users can visually compose their application logic. Support for Vector Graphics ensures more brilliant HMI graphics with lower memory footprint. An improved State Machine Editor comes with plenty of options to visually enrich your specification, and the Player allows for rotation and seamless scaling of GUIs in the making. The upgraded Help System now offers dynamic documentation incl. search and history as well as support for multiple languages – perfect for international teams, beginners and HMI Pros who want to further speed up their HMI game.

Want to see for yourself? Watch the CGI Studio 3.12 film!

A free trial of CGI Studio is also available.

Fig. 1: CGI Studio 3.12: High-performance HMI creation – the intelligent way.

Enhanced Smart Importer: Figma Cloud Import & better AI

The Smart Importer is Candera’s award-winning technology that lets users import graphics files directly into CGI Studio. During the import, its innovative AI detects industry standard controls such as gauges, sliders, and buttons – and automatically adds their proper functionality.

Significant improvements of the Smart Importer made this detecting process more precise and easier to use – for more accurate control mapping via AI.

The Smart Importer has been supporting the import of graphics files from Adobe Photoshop®, Sketch, Axure RP, and Adobe XD for a while. The direct import of Figma files, including support of the cloud interface, is the latest addition to a growing list of supported tools.

Fig. 2: Figma import directly from the cloud in CGI Studio 3.12

Candera’s Smart Importer speeds up the whole HMI creation process by providing a direct preview, full re-import for quick design iterations, and image merging to reduce the memory footprint.

Fusion Editor: Visual Composition of Logic

 In the 3.12 release, Candera has introduced the Fusion Editor in CGI Studio for the first time. The Fusion Editor allows users to easily compose the application logic in a graphical manner and combine it with the user interface. This feature is aimed at users without any programming skills and is intended to make HMI creation more accessible for everyone.

Fig. 3: Fusion Editor: Visual composition of logic and behaviors.

Support for Vector Graphics: Go Big!

There are many advantages to vector graphics: Their scalability, their small file size even when scaled very large, that they are easy to edit, load, modify, and duplicate.

In CGI Studio 3.12, vector graphics can now be used in HMIs – for creating even more brilliant Graphical User Interfaces. Users can simply import SVG files into the Scene Composer and use them as they would any other graphics file.

State Machine Editor: Design your Specification

Significant improvements in CGI Studio 3.12’s State Machine now allow for users to design their screen transition specifications with flexible use of screenshots, custom images, colors, or even annotations. Elements of the state machine have become “designable”, so users can design their state flows according to their needs. For better overview, more efficient HMI creation and in the end: Faster time to market.

Fig. 4: State Machine Editor: Individually designable state machine for better overview.

State Machine Editor – NEW: Pseudostates
The improved state machine Editor of CGI Studio 3.12 now also gives users the option to work with pseudostates. A pseudostate is used to simplify specifications of multiple state transitions. It combines and encompasses multiple direct transitions like forks.

   Fig. 5: A) state machine with two transitions vs. B) state machine with two transitions WITH pseudostate.

CGI Studio Player: Rotate and Zoom

Speaking of ‘What You See Is What You Get’: CGI Studio’s Player lets users view their HMI right away. With the latest upgrade, it is now also possible to fit one’s HMI simulation to one’s screen while rotating it any way one needs – as well as scaling it to any size necessary. HMI simulation has never been more comfortable.

Fig. 6: CGI Studio Player: Easy rotation and zoom.

Upgraded Help System: Dynamic – and in your language

A clearly structured, extensive help system is the basis for fast on-boarding and overall effective use of any design tool. In CGI Studio 3.12, a new dynamic documentation including search & history get users to their answers faster. Also, a new look & feel with images and multimedia content makes looking for answers more effective and enjoyable. Lastly, the updated help system provides support for multiple languages.

Fig. 7: Help & Documentation: Answers to any question, here in Japanese.

Further improvements include an extended set of 3D Primitives for users to quickly draft their 3D scene.
The Extended Android support now includes features such as runtime resource overlay (RRO), virtual display support and revised touch & keyboard input.

Fig. 8: CGI Studio 3.12 provides a large number of 3D Primitives.

For more, watch the CGI Studio 3.12 Highlights video.

Not quite convinced yet?

Request a trial version of CGI Studio.

Learn more about CGI Studio: Website          Facebook          YouTube          Twitter          LinkedIn

Candera Studio: Introducing Fusion Editor’s “Super Sets”

Super Sets are templates for logic blocks, which significantly speed up and simplify the HMI creation process: Users are now able to re-use blocks of logic, that they created for specific needs of their HMI. But that is not all: Candera Studio’s Feature Pack 2 comes with improvements of the state machine, “smart render” state caching to accelerate render performance, and advances in both the data source editor and font engine.

Candera Studio is the new HMI creation software for industrial, medical, and white goods industries, as well as other advanced embedded or individual HMIs. Easily accessible, intuitive to use – even for users without any coding experience – Candera Studio accepts any input (graphical files) and is set up to output to any embedded hardware on which user interfaces are displayed. Candera is opening to new users and new markets – highlighting Candera’s mission statement: “Candera is where Humans and Machines Interact: In displays of embedded devices.”

Now there is the first update. What is new about Candera Studio? Here is a sneak preview:

Fusion Editor’s “Super Sets”

Candera Studio’s Fusion Editor now includes a new feature called Super Sets. Users can easily merge complex logic into easy-to-use templates, share and re-use Super Sets within and across projects, and tailor the interface of Super Sets for high usability.

Fig. 1: Fusion Editor Super Sets: The template nodes are marked with the golden Super Set icon.

In short: combine custom Fusion diagrams in re-usable templates for simplified use. Once you have created one set of logic, it becomes much more efficient to re-use it for similar applications. For more, watch the Fusion Super Sets film.

Fig. 2: Fusion Editor Super Sets: Re-use logical blocks you have created before.

A free trial version is now available.

State Machine Improvements

Candera Studio’s improved State Machine lets users design their screen transition specifications with flexible use of images, such as screenshots or snapshots, as well as annotations and individual coloring solutions.

Another step towards making the tool even more intuitive to work with: better integration of key-shortcuts or support for zoom levels.

Fig. 3: State Machine: more intuitive to use

Increased Rendering Performance

For Candera Studio’s Feature Pack 2, render performance has been optimized by smart render state caching to accelerate render performance. Users benefit from optimized render stability in conjunction with rendering of vector graphics

Fig. 4: Smart render state caching for accelerated render performance

Advanced Data Source Editor

Candera Studio’s Data Source Editor now supports a broad set of complex data types: Vector 2, Vector 3, Vector 4, Colour, Asynchronous List, and Rectangle. Additionally, support for global data items has been added to easily share data between multiple scenes

Monotype Font Engine

The professional Monotype font engine is fully integrated in Candera Studio and used to render fonts. Supporting shaping, the optimized 2D Basic Sample showcases high-quality Monotype fonts for a wide variety of use cases. Beyond improving visual appearance, the right choice of fonts can ensure safety requirements for HMIs in critical applications or ensure a globally uniform brand appearance across many languages.

Further improvements include a powerful dynamic list control (for more, watch the video), JavaScript samples, improved Adobe XD import for the Smart Importer, UI/UX optimizations for the Fusion Editor.

For those new to Candera Studio, a quick reminder:

Candera’s latest innovation is the HMI software toolchain Candera Studio – for industrial applications. It is an intuitive, noncoding HMI software tool – clearly “designed for designers”. For easy access, especially faster on-boarding, with multi-language documentation, and detailed tutorials.

Designed to be open: to be integrated “from any input” i.e., various graphics tools – “to any output” i.e., operating systems and hardware.
Presenting for the first time the Fusion Editor for intuitive visual composition of logic and behaviors: No coding skills necessary.

KAGA FEI Co., Ltd.

Candera Studio includes ready-to-use controls, automated workflows, integrated state machine and an AI-powered Smart Importer. It uses artificial intelligence to recognize relevant components such as buttons, sliders, gauges, etc., and suggests the appropriate function for each element. Simply select the appropriate component and define its property. Check the result immediately in a simulation of the Candera Studio Player. In a few minutes, you have created a fully functional HMI.
